Click to Enlarge

TOA HA1010AS LONG RANGE HORN ARRAY

Stock Code:

HA1010AS

Downloads

Download Information

Details

Unit of Measure:

Indent

Description

The TOA Long Range Slim Array Speaker is composed of multiple horn speakers positioned in an array. It features long-range sound coverage, further than that of multiple conventional horn speakers grouped together. Narrowly focused vertical directivity allows high volumes to be controlled at closer proximity.

Rated input: 60w
SPL (dB): 114 (1w @1m)
Max SPL (dB) 132 (60w @1m)
Freq Response: 350Hz-7kHz
Directivity Angle: Horziontal 90 degrees Vertical 15 degrees
Speaker Component: Horn Driver x 8
IP66
Dimensions: 167mm x 1233mm x 140.5mm (WxHxD)
Weight: 13.5kg
