Ness M1 RB Relay Board
Stock Code:
101-213
Downloads
Details
-
Unit of Measure:Each
Description
May be plugged directly into an M1G, M1XOV, or M1XOVR to convert the voltage outputs into SPDT relays rated for 7A @ 30 VDC, 10A @ 125 VAC. FEATURES: • 8 Form "C" Relays, SPDT Dry Contact • Heavy Duty Contact Rating • Low Current Draw. • Great For General Purpose Switching. • Plug-in "Removable" Terminal Blocks • LED Status Indicators on all 8 Relays • Twelve (12) Conductor Plug-in Wire Harness • Mounts in Enclosure using SWG Glides SPECIFICATIONS: • Diode Protection Across Relay Coil. • Contact Ratings: 12 Amps @ 28 VDC, 125 VAC • Wire Harness Length: 600mm • Operating Voltage: 12 Volts DC Nominal • Current Draw: 0 mA idle, 250 mA Max. • Size: 152 x 82.5 x 19mm H
